9 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology
Inconel 713c 9 Blade Turbine Wheel
Multiple options for turbine housing
V-Band Flange kit(s) for the exhaust housing included
Max Air Flow rate: 65 lb/min, rated @ 750 FWHP
Compressor Wheel: 58*76mm
Turbine Wheel: 68*62mm
Compressor Inlet: 3.0†Hose
Compressor Outlet: 2.0†Hose
Turbine Inlet: T3, T4, or 2.5″ V-Band
Turbine Outlet: 3″ V-Band (3.55″OD)
Oil Feed: -4 AN connect to the Oil Restrictor
Oil Drain: Std T3 Flange
Water In/Outlet: M14*1.5
We highly recommended running water cooling for better durability.
Note: We strive to maintain a wide range of products in stock. However, some items may be ordered on demand, resulting in a lead time. If your order is urgent, please contact Speedspec in advance. sales@speedspec.co.nz
