9 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology
Inconel 713c 10 Blade Turbine Wheel
Multiple options for turbine housing
V-Band Flange kit(s) for the exhaust housing included
Max Air Flow rate: ~65 lb/min, rated @ 750 FWHP
Compressor Wheel: 58*76mm
Turbine Wheel: 60*55mm
Compressor Inlet: 3″ Hose
Compressor Outlet: 2″ Hose
Turbine Inlet: T3, T4 or 2.5″ V-Band
Turbine Outlet: 3″ V-Band (3.55″OD)
Oil Feed: -4 AN connect to the Oil Restrictor
Oil Drain: Std T3 Flange
Water In/Outlet: M14*1.5
We highly recommended running water cooling for better durability.
Compact turbos are great for applications where there is less space
