Aeroflow

SKU:AF8005-4041

BOOSTED 7975 1.15 T4 V-BAND OUTLET G42

BOOSTED 7975 1.15 T4 V-BAND OUTLET G42

Regular price $2,139.00NZD
Regular price $2,300.00NZD Sale price $2,139.00NZD
Sale Sold out
Shipping calculated at checkout.
COLOUR
BOOSTED 7975 T4 Turbocharger Specifications

Recommended horsepower rating:  475-1450HP
Recommended engine displacement:  2.0L to 8.0L

- Dual ceramic ball bearing
- Point Milled 7075 billet compressor wheel
- Ported shroud compressor cover
- Speed sensor port included in compressor cover (Speed sensor sold separately, AF8050-1010)
- 1/8" NPT boost reference port
- External wastegate sold separately
- Inlet flange gasket, turbo drain gasket and -4AN turbo oil feed fitting with restrictor included in turbo kit. (Warranty VOID if not used)
- T4 twin entry turbine inlet flange
- 9 blade turbine wheel
- SiMo-nodular cast iron rear housing
- V-Band turbine outlet flange
- M14 x 1.5mm coolant port thread
- 1/4" NPT to -4AN oil feed fitting with in-built restrictor attached to a 38mm 2-bolt oil feed plate with M8 x 1.25mm thread size
- 50.80mm bolt centre turbo drain flange with M8 x 1.25mm thread size

Compressor Specifications
Inducer:  79mm
Exducer:  98mm
Extended Tip:  103mm
A/R:  0.85
Compressor Inlet:  5" Slip fit
Compressor Outlet: V-Band (AF8080-1009)

Turbine Specifications
Inducer:  82mm
Exducer:  75mm
A/R:  1.15
Turbine Inlet Flange: T4
Turbine Outlet Flange:  V-Band (AF8080-1020)

Wastegate
External wastegate
