Recommended horsepower rating: Â 200-475HP Recommended engine displacement: Â 1.4L to 2.5L
- Dual ceramic ball bearing - Billet aluminium compressor wheel - Ported shroud compressor cover - Speed sensor port included in compressor cover (Speed sensor sold separately, AF8050-1010) - Inlet flange gasket, turbo drain gasket and -4AN turbo oil feed fitting with restrictor included in turbo kit. (Warranty VOID if not used) - T25 / T28 single entry turbine inlet flange - SiMo-nodular cast iron rear housing - 5-bolt turbine outlet flange - M14 x 1.5mm coolant port thread - 7/16"-24 oil feed fitting thread - 38mm bolt centre turbo drain flange with M8 x 1.25mm thread size - M8 x 1.25mm 5-bolt turbine outlet flange - Internal wastegate actuator with 8.7psi spring
Compressor Specifications Inducer: Â 46mm Exducer: Â 60.1mm Extended Tip: Â 62.24mm A/R: Â 0.60 Compressor Inlet: Â 3" Slip fit Compressor Outlet: Â 2" Slip fit
Turbine Specifications Inducer: Â 53.9mm Exducer: Â 47mm A/R: Â 0.86 Turbine Inlet Flange: Â T25 / T28 Turbine Outlet Flange: Â 5-Bolt
Wastegate Internal wastegate with 8.7psi actuator
