BOOSTED 5862 1.06 T3 XR6 FG BA5 BOLT OUTLET GTX3576
SKU AF8005-3013
Original price
$1,500.00
-
Original price
$1,500.00
Original price
$1,500.00
$1,500.00
$1,500.00
-
$1,500.00
Current price
$1,500.00
Availability:
Available from supplier allow 2–10 days to ship
BOOSTED 5862 XR6 Turbocharger Specifications
Recommended horsepower rating: Â 400-750HP
Recommended engine displacement: Â 2.5L to 4.5L
- Dual ceramic ball bearing
- Point Milled 7075 billet compressor wheel
- Ported shroud compressor cover
- Speed sensor port included in compressor cover (Speed sensor sold separately, AF8050-1010)
- SiMo-nodular cast iron rear housing
- Standard 5-Bolt XR6 turbine outlet flange
- T3 single entry turbine inlet flange
- M14 x 1.5mm coolant port thread
- 7/16"-24 oil feed fitting with in-built restrictor (Warranty VOID if not used)
- 38mm bolt centre turbo drain flange with M8 x 1.25mm thread size
- Suits both Ford XR6 BA/BF and FG. Turbo housing will be supplied in FG configuration
- Billet Internal wastegate actuator with 9psi spring (different rate springs sold separately)
- Internal wastegate hole size is 32mm
- New boost reference port is required for this turbocharger. Install boost reference port into front compressor cover or intercooler piping to suit the OEM boost controller
Compressor Specifications
Inducer: Â 58mm
Exducer: Â 76.2mm
Extended Tip: Â 80.42mm
A/R: Â 0.60
Compressor Inlet: Â 4" Slip fit
Compressor Outlet: Â 2" Slip fit
Turbine Specifications
Inducer: Â 68mm
Exducer: Â 62.3mm
A/R: Â 1.06
Turbine Inlet Flange: Â T3
Turbine Outlet Flange: Â XR6 5-Bolt
Wastegate
Internal wastegate featuring 32mm port and 9psi actuator
Recommended horsepower rating: Â 400-750HP
Recommended engine displacement: Â 2.5L to 4.5L
- Dual ceramic ball bearing
- Point Milled 7075 billet compressor wheel
- Ported shroud compressor cover
- Speed sensor port included in compressor cover (Speed sensor sold separately, AF8050-1010)
- SiMo-nodular cast iron rear housing
- Standard 5-Bolt XR6 turbine outlet flange
- T3 single entry turbine inlet flange
- M14 x 1.5mm coolant port thread
- 7/16"-24 oil feed fitting with in-built restrictor (Warranty VOID if not used)
- 38mm bolt centre turbo drain flange with M8 x 1.25mm thread size
- Suits both Ford XR6 BA/BF and FG. Turbo housing will be supplied in FG configuration
- Billet Internal wastegate actuator with 9psi spring (different rate springs sold separately)
- Internal wastegate hole size is 32mm
- New boost reference port is required for this turbocharger. Install boost reference port into front compressor cover or intercooler piping to suit the OEM boost controller
Compressor Specifications
Inducer: Â 58mm
Exducer: Â 76.2mm
Extended Tip: Â 80.42mm
A/R: Â 0.60
Compressor Inlet: Â 4" Slip fit
Compressor Outlet: Â 2" Slip fit
Turbine Specifications
Inducer: Â 68mm
Exducer: Â 62.3mm
A/R: Â 1.06
Turbine Inlet Flange: Â T3
Turbine Outlet Flange: Â XR6 5-Bolt
Wastegate
Internal wastegate featuring 32mm port and 9psi actuator
